Specifications

Tonnage (tons) 10

Machine operating weight (kg) 9560-10172

Bucket width (mm) 2470

Bucket capacity (m³) 0.45

Boom length (mm) 4300

Arm length (mm) 2500

Performance

Slewing speed (rpm) 10.6

Travel speed (km/h) 2.6-4.9

Gradability (%) 70

Bucket digging force (kN) 77.7

Arm digging force (KN) 49.2

Maximum traction force (KN) 84.8

Power system

Engine model Cat C3.3

Rated power (kw/rpm) 55.4

Displacement (L) 3.33

Bore × stroke (mm) 94 × 120

Hydraulic system

Main pump maximum flow (I/min) 233

Oil capacity

Fuel tank (L) 145

Hydraulic oil tank (L) 53

Hydraulic system (L) 140

Engine oil change volume (L) 11

Descriptions

These machines are in a good working condition, the engine power is strong enough, the main core components including the engine, hydraulic pump, distribution valve and rotating motor, all of them are original.the mechanical matching and hydraulic system of these machines performed well and they are durable, cost-effective and flexible when it's working.
